Rectangular High Precision Aspheric Lenses

×
  • 정사각형 및 사각형, 5 x 5mm 크기부터 공급
  • 0.25µm RMS의 비구면 형상 오차
  • 공간 제약적인 레이저 시스템에 사용하기 적합

공통 스펙

Bevel:
Protective bevel as needed
Shape of Back Surface:
Plano
Asphere Figure Error, RMS @ 632.8nm:
0.4λ
Coating:
Uncoated
Surface Quality:
40-20
Conjugate Distance:
Infinite
 Dimensions (mm)  NA EFL (mm) BFL (mm) CT (mm)  Substrate   제품 비교하기   재고 번호   가격(부가세 별도)  구입하기
5.00 x 10.00 0.50 10.00 5.68 7.80 N-SF6 #17-303 재고정리 KRW 229,100   견적 요청
  • 3~5일내 배송
    ×

10.00 x 15.00 0.50 15.00 10.22 8.62 N-SF6 #17-307 KRW 391,500 수량 6+ KRW 313,200   견적 요청
  • 3~5일내 배송
    ×

10.00 x 10.00 0.33 15.00 10.22 8.62 N-SF6 #17-308 KRW 414,700 수량 6+ KRW 332,100   견적 요청
  • 3~5일내 배송
    ×

10.00 x 15.00 0.66 11.25 5.71 10.02 N-SF6 #17-309 KRW 414,700 수량 6+ KRW 332,100   견적 요청
  • 3~5일내 배송
    ×

10.00 x 10.00 0.44 11.25 5.71 10.02 N-SF6 #17-310 KRW 407,500 수량 6+ KRW 326,300   견적 요청
  • 3~5일내 배송
    ×

12.50 x 25.00 0.25 50.00 45.23 7.24 N-BK7 #17-311 KRW 490,100 수량 6+ KRW 391,500   견적 요청
  • 3~5일내 배송
    ×

12.50 x 12.50 0.13 50.00 45.23 7.24 N-BK7 #17-312 KRW 490,100 수량 6+ KRW 391,500   견적 요청
  • 3~5일내 배송
    ×

12.50 x 25.00 0.33 37.50 31.09 9.72 N-BK7 #17-313 재고정리 KRW 490,100 수량 6+ KRW 391,500   견적 요청
  • 3~5일내 배송
    ×

12.50 x 12.50 0.17 37.50 31.09 9.72 N-BK7 #17-314 재고정리 KRW 490,100 수량 6+ KRW 391,500   견적 요청
  • 3~5일내 배송
    ×

12.50 x 12.50 0.20 31.25 23.67 11.50 N-BK7 #17-316 재고정리 KRW 345,100   견적 요청
  • 3~5일내 배송
    ×


TECHSPEC® Rectangular High Precision Aspheric Lenses는 당사 제품인 TECHSPEC High Precision Aspheric Lenses를 절삭한 버전입니다. 이 비구면 렌즈는 0.25µm RMS의 비구면 형상 오류를 달성하기 위해 CNC 연마 가공을 거친 뒤 정사각형 혹은 사각형으로 커팅 처리가 됩니다. 이처럼 정밀한 비구면 형상 오류를 제공하는 이 렌즈는 구면 수차 보정을 필요로 하는 까다로운 이미징 또는 레이저 시스템에 사용하기 적합합니다. 소형 크기의 공간 절약형 TECHSPEC Rectangular High Precision Aspheric Lenses는 의료 장비, 생명 과학 기기, 산업용 레이저 시스템에 결합해서 사용하기 적합합니다. 고객의 어플리케이션 요건에 따라 TECHSPEC Aspheric Lens를 절삭한 버전이 필요한 경우 당사로 문의 바랍니다.
